A Eighties-era semiconductor fab in Austin, Texas, is getting a makeover. The Texas Institute for Electronics (TIE), because it’s known as now, is tooling as much as turn out to be the one superior packaging plant on the earth that’s devoted to 3D heterogenous integration (3DHI)—the stacking of chips product of a number of supplies, each silicon and non-silicon.
The fab is the infrastructure behind DARPA’s Next-Generation Microelectronics Manufacturing (NGMM) program. “NGMM is targeted on a revolution in microelectronics by way of 3D heterogeneous integration,” stated Michael Holmes, managing director of this system.
Stacking two or extra silicon chips inside the identical bundle makes them act as if they’re all one built-in circuit. It already powers a few of the most advanced processors on the earth. However DARPA predicts silicon-on-silicon stacking will lead to not more than a 30-fold increase in efficiency over what’s potential with 2D integration. In contrast, doing it with a mixture of supplies—gallium nitride, silicon carbide, and different semiconductors—may ship a 100-fold increase, Holmes instructed engineers and different events on the program’s unofficial popping out occasion, the NGMM Summit, late final month.
The brand new fab will make certain these uncommon stacked chips are prototyped and manufactured in the USA. Startups, and there have been many on the launch occasion, are searching for a spot to prototype and start manufacturing concepts which can be too bizarre for anyplace else—and hopefully bypassing the lab-to-fab valley of loss of life that claims many {hardware} startups.
The state of Texas is contributing $552 million to face up the fab and its applications, with DARPA contributing the remaining $840 million. After NGMM’s five-year mission is full, the fab is predicted to be a self-sustaining enterprise. “We’re, frankly, a startup,” stated TIE CEO Dwayne LaBrake. “We’ve extra runway than a typical startup, however we now have to face on our personal.”
Beginning up a 3DHI Fab
Attending to that time will take lots of work, however the TIE foundry is off to a fast begin. On a tour of the power, IEEE Spectrum noticed a number of chip manufacturing and testing instruments in numerous states of set up and met a number of engineers and technicians who had began inside the final three months. TIE expects all of the fab’s instruments to be in place within the first quarter of 2026.
Simply as vital because the instruments themselves is the power of foundry clients to make use of them in a predictable manufacturing course of. That’s one thing that’s significantly tough to develop, TIE officers defined. On the most simple stage, non-silicon wafers are usually not the identical dimension as one another. And so they have completely different mechanical properties, that means they increase and contract with temperature at completely different charges. But a lot of the fab’s work can be linking these chips along with micrometer precision.
The primary section of getting that executed is the event of what are known as a course of design equipment and an meeting design equipment. The previous supplies the principles that constrain semiconductor design on the fab. The latter, the meeting design equipment, is the true coronary heart of issues, as a result of it provides the principles for the 3D assembly and other advanced packaging.
Subsequent, TIE will refine these by the use of three 3DHI tasks, which NGMM is asking exemplars. These are a phased-array radar, an infrared imager known as a focal airplane array, and a compact energy converter. Piloting these by way of manufacturing “provides us an preliminary roadmap… an on-ramp into super innovation throughout a broader software area,” stated Holmes.
These three very completely different merchandise are emblematic of how the fab must function as soon as it’s up and working. Executives described it as a “high-mix, low-volume” foundry, that means it’s going to must be good at doing many various issues, but it surely’s not going to make lots of anybody factor.
That is the alternative of most silicon foundries. A high-volume silicon foundry will get to run numerous comparable check wafers by way of its course of to work out the bugs. However TIE can’t try this, so as a substitute it’s counting on AI—developed by Austin startup Sandbox Semiconductor—to assist predict the end result of tweaks to its processes.
Alongside the best way, NGMM will present quite a few analysis alternatives. “What we now have with NGMM is a really uncommon alternative,” stated Ted Moise, a professor at UT Dallas and an IEEE Fellow. With NGMM, universities are planning to work on new thermal conductivity movies, microfluidic cooling know-how, understanding failure mechanisms in complicated packages, and extra.
“NGMM is a bizarre program for DARPA,” admitted Whitney Mason, director of the company’s Microsystems Expertise Workplace. “It’s not our behavior to face up services that do manufacturing.”
However “Maintain Austin Bizarre” is town’s unofficial motto, so possibly NGMM and TIE will show an ideal match.
